Docker+Prometheus+Grafana监控VPS运行状态

安装

[!NOTE]

首先安装docker/docker-compose：

apt -y update
apt -y install curl
curl -sSL https://get.docker.com/ | sh
systemctl start docker
systemctl enable docker
curl -L https://github.com/docker/compose/releases/download/1.25.4/docker-compose-`uname -s`-`uname -m` -o /usr/local/bin/docker-compose
chmod +x /usr/local/bin/docker-compose

1)使用docker-compose安装Prometheus和Grafana服务

docker-compose.yml内容如下

version: '3.5'

volumes:
  prometheus-data:
  grafana-data:

services:
  prometheus:
    image: prom/prometheus
    container_name: prometheus
      #ports:
      #    - 9090:9090
    volumes:
      - prometheus-data:/prometheus
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
    command:
      - '--config.file=/etc/prometheus/prometheus.yml'
      - '--web.enable-admin-api'
      - '--web.enable-lifecycle'
      - '--storage.tsdb.retention.time=200h'

    logging:
      options:
        max-size: 10m
    networks:
      - localnet

  grafana:
    image: grafana/grafana
    container_name: grafana
    networks:
      - localnet
    #ports:
    #    - 3000:3000
    volumes:
      - grafana-data:/var/lib/grafana
    logging:
      options:
        max-size: 10m

networks:
  localnet:
    external: true

因为nginx服务后端接入的服务不止prometheus，所以将nginx的docker服务拆到其他docker-compose文件中。网络共用localnet，这样nginx就可以通过容器名称直接访问prometheus服务。

创建本地docker网络，命令如下

1	`docker network create localnet`

根据自己服务的情况，选择存储的retention配置，我这里是--storage.tsdb.retention.time=200h，还可以配置--storage.tsdb.retention.size

添加prometheus.yml

global:
    scrape_interval: 60s
    external_labels:
        monitor: 'self-hosted'

scrape_configs:
    - job_name: 'prometheus'
      static_configs:
          - targets:
                - 'localhost:9090'
            labels:
                instance: prometheus

    - job_name: 'VPS监控'
      static_configs:
          - targets:
                - '需要监控的vps的IP:19898'
            labels:
                instance: 'vps1'
          - targets:
                - '需要监控的vps的IP:19898'
            labels:
                instance: 'vps2'

此时docker-compose up -d 启动服务跑起来就好了。

2）配置nginx反向代理

docker-compose.yml文件如下，使用cloudflare的证书最多可以15年，letsencrypt每3个月需要更新一次。

version: "3.5"

networks:
  localnet:
    external: true

services:
  nginx:
    image: nginx:1.19.10
    environment:
      TZ: Asia/Shanghai
    restart: always
    container_name: nginx
    volumes:
      - ./data/nginx:/etc/nginx/conf.d
      - ./data/cfcert:/etc/cfcert
    ports:
      - 80:80
      - 443:443
    networks:
      - localnet
    logging:
      options:
        max-size: 10m

公网服务的反代配置-monitor.conf

server {
    listen 80;
    server_name 你的域名;

    location / {
        return 301 https://$host$request_uri;
    }
}
upstream grafana-server{
    server grafana:3000;
}
server {
    listen 443 ssl;

    server_name 你的域名;
    ssl_certificate /etc/cfcert/你的域名.pem;
    ssl_certificate_key /etc/cfcert/你的域名.key;
        #添加如下内容即可防止爬虫
        if ($http_user_agent ~* "qihoobot|Baiduspider|Googlebot|Googlebot-Mobile|Googlebot-Image|Mediapartners-Google|Adsbot-Google|Feedfetcher-Google|Yahoo! Slurp|Yahoo! Slurp China|YoudaoBot|Sosospider|Sogou spider|Sogou web spider|MSNBot|ia_archiver|Tomato Bot")
        {
        return 403;
        }
    location / {
        proxy_pass http://grafana-server;
        proxy_redirect     off;
        proxy_set_header   Host             $host;
        proxy_set_header   X-Real-IP        $remote_addr;
        proxy_set_header   X-Forwarded-For  $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto https;
    }
}

docker-compose up -d 启动nginx服务，就可以通过你的域名访问grafana面板了。

3)在需要监控的vps节点上安装node_exporter

1
2
3

wget https://github.com/prometheus/node_exporter/releases/download/v1.1.2/node_exporter-1.1.2.linux-amd64.tar.gz

tar -zxvf node_exporter-1.1.2.linux-amd64.tar.gz

设置node_exporter为自启动服务

1
2
3

cd node_exporter-1.1.2.linux-amd64/
cp node_exporter /usr/bin
vi /etc/systemd/system/node_exporter.service

node_exporter.service内容如下，node exporter默认端口为9100，这里修改为19898：

[Unit]
Description=Node Exporter

[Service]
User=root
ExecStart=/usr/bin/node_exporter   --web.listen-address=:19898

[Install]
WantedBy=multi-user.target
systemctl start node_exporter.service
systemctl enable node_exporter.service
